Overview

With the slimmest bezel in the 60” diagonal class*, the PN-V601A is the new standard for multi-screen video wall displays. Portrait and landscape compatible, full array LED backlighting and virtually seamless borders help you create high impact video walls in almost any size and format.

Designed for sophisticated video wall applications, the PN-V601A offers the world’s slimmest bezel1 available on a 60-inch class professional LCD monitor. As a flexible digital signage solution with 24/7 certified reliability and an almost seamless bezel (just 6.5 mm total between neighboring monitors), the PN-V601A sets a new standard for video wall displays. A full-array LED backlight helps ensure uniform brightness, and an enlarge (zoom) display mode enables one image to be expanded across up to 25 monitors (in a 5x5 configuration). An optional PN-ZR01 Control Kit permits all monitors in a video wall to be operated using a single remote, and the optional PN-ZB02 Interface Expansion Board expands the input/output capability of each display.

*Simulated screen images. Video wall images shown include multiple PN-V601A displays.

Features

  • 60" Class (60" Diagonal) Screen Size - with Sharp UV2A LCD Technology provides exceptionally deep blacks and bright vivid colors with up to 700 cd/m2 brightness and 4000:1 contrast ratio.
  • World’s Slimmest Bezel - (Based on available information, as of June 8, 2010, for LCD panels of 46-inches or larger in size.) Thanks to its ultra-slim bezel, multiple PN-V601A monitors can be joined together to create high impact multi-screen displays. The width of the bezel between neighboring monitors in a multi-screen display is only 6.5 mm (2.4mm on the right and bottom, and 4.1 mm on the left and top). (Total non-display area for neighboring monitors is 7.1 mm.)
  • Full Array LED Backlight - gives the PN-V601A more uniform brightness than conventional CCFL backlighting. LED elements are positioned across the entire panel directly behind the liquid crystal layers, helping ensure beautiful uniform images.
  • 1366 x 768 Resolution - from analog RGB, digital RGB and HDTV video sources. When used in a 3x3 video wall display, this Professional LCD Monitor provides over 4K x 2K total resolution (4098 x 2304 pixels) for ultra-high resolution / ultra-high impact images.
  • Enlarge (Zoom) Display Mode - enables one image to be spread across up to 25 monitors (in up to a 5x5 configuration). The Frame Width Adjustment function eliminates misalignment and helps enhance the enlarged image in a multi-screen display.
  • 24/7 Certified - for use in most commercial applications.
  • 3-Year On-Site Limited Warranty - covers parts, labor and backlight in both landscape and portrait modes.
